Ragal 1-Bay 3-Level Pallet Racking

Ragal Pallet Racking offers uprights in 80–120mm widths, supporting bay loads up to 25 tonnes and heights up to 7500mm in a single piece. With a 50mm pitch for precise adjustment, the system utilises open or boxed beams carrying up to 7200kg per pair across spans of 1350–3900mm. Designs adhere to a 1/200 deflection limit or a safety factor of 2. Extensive accessories include column guards, crash barriers, decking, support bars, fork clearance bars, drum chocks and guide rails. Finishes include durable powder coating (blue/grey/orange) or galvanisation for outdoor cantilever use. Note: 4000kg Bay Max Load not available for W3300/3600xD900/1100xH4000/4500/5000mm
